Universal Washing Machine PCB Board Kit for Top Load Washing Machine Main Control Board with Display Panel, Water Level Sensor & Connecting Wires Heavy Duty Universal PCB (1 Year Warranty)

Important: Installation involves mains electricity and electronic components. The installation should be performed by a qualified washing-machine technician. Step 1 – Disconnect Power Switch OFF the washing machine and remove the mains plug before starting any work. Step 2 – Access the Existing PCB Remove the top control-panel cover according to the washing machine's construction and locate the existing main PCB. Step 3 – Photograph Existing Wiring Before disconnecting anything, take clear photographs of the existing PCB and all wire/connector positions. This is extremely important when replacing a universal board. Step 4 – Disconnect the Old PCB Carefully disconnect the existing connectors and wires from the old PCB. Step 5 – Remove Old Control Board Remove the screws/clips holding the old PCB and take it out carefully. Step 6 – Install the New PCB Position the universal PCB securely in the control-panel area. Ensure that it is properly insulated and firmly mounted. Step 7 – Connect Wiring Connect the wires according to the PCB wiring configuration and the washing machine's circuit requirements. Do not connect wires based only on colour. Verify each connection and terminal function before powering the machine. Step 8 – Install Display Panel Mount the supplied universal display/control panel and connect its ribbon cable securely to the PCB. Step 9 – Install Water-Level Sensor Install the water-level sensor in the appropriate position and connect its wiring/tube correctly according to the kit's configuration. Step 10 – Check All Connections Before switching ON the machine, verify: - PCB power connection - Motor connection - Drain pump connection - Inlet valve connection - Water-level sensor - Display/ribbon cable - Lid/safety switch - Any other applicable connectors Step 11 – Reassemble Secure the PCB and display panel, arrange the wires safely and reinstall the washing-machine control-panel cover. Step 12 – Test Restore power and test the machine's applicable functions: Power → Water Filling → Water Level → Wash → Rinse → Drain → Spin → Program Selection → Display Important Compatibility Warning Please compare your original PCB and wiring before purchasing. Universal washing-machine PCB kits are not automatically compatible with every top-load washing machine. Check especially: - Number and type of connectors - Motor type - Motor wiring - Drain pump - Inlet valve - Water-level sensor - Lid/safety switch - Display connector - Wash-program configuration - PCB mounting arrangement - Power supply specification This will help prevent PCB damage and incorrect machine operation.
