2 Way Water Inlet Valve for Washing Machine AC 220-240V Compatible with IFB & LG Hot & Cold Water Inlet 2 Year Warranty

Technovate 2-Way Water Inlet Valve – Washing Machine ⚠️ Safety First: Installation should be performed by a qualified washing-machine technician. Disconnect the washing machine from the electrical supply and close the water inlet tap before starting. Step-by-Step Installation 1. Switch OFF the Washing Machine Turn OFF the washing machine. Unplug the power cable completely. Close the water supply tap. 2. Remove the Top Cover Remove the screws securing the washing-machine top cover. Carefully lift/remove the cover to access the water inlet valve. 3. Identify the Existing Inlet Valve Locate the existing 2-way water inlet valve where the external water hose connects to the machine. Take a photo of the existing wiring and hose connections before removing them. 4. Disconnect the Electrical Connectors Carefully remove the electrical connectors from the old valve. Hold the connector while disconnecting it. Do not pull directly on the wires. 5. Disconnect the Water Hoses Remove the internal water hoses connected to the old valve. Keep clamps safely for reuse if applicable. Be prepared for a small amount of residual water. 6. Remove the Old Valve Remove the mounting screw(s) or clips securing the inlet valve. Carefully remove the old valve from the washing machine. 7. Install the New Valve Position the new Technovate 2-Way Inlet Valve in the same orientation as the original. Secure it firmly using the original mounting arrangement. 8. Connect the Water Hoses Connect each hose to the correct water outlet/port. Secure the hose clamps properly. Make sure the hoses are not kinked or loose. 9. Connect the Electrical Terminals Reconnect the electrical connectors to the corresponding terminals. Do not interchange the wiring or connect terminals based only on wire colour. Ensure every connector is firmly seated. 10. Refit the Top Cover Check that all hoses and wires are properly positioned. Reinstall the washing-machine top cover and screws. 11. Check for Water Leakage Open the water supply tap slowly. Inspect all hose connections and the inlet valve for leakage. If you see any leakage, close the water supply immediately and correct the connection. 12. Test the Washing Machine Reconnect the washing machine to the electrical supply. Start a suitable wash program. Check that water enters the machine properly through the required inlet. Check both water-inlet channels if the washing machine uses both. Confirm there is no water leakage or abnormal operation. ⚠️ Important Compatibility & Safety Warning Before installation, confirm that the replacement valve matches the original valve in: 2-way configuration FPS180A specification AC 220–240V / 50–60Hz Electrical connector/terminal arrangement Water-port configuration Mounting arrangement
